Christie® Entero™ HB is an evolution in performance, reliability and confidence for control room video wall displays.
Performance – Leading the progression to higher brightness LED displays, Christie has developed Christie Entero HB – the newest generation of high-performance, high-brightness display wall cubes. With the most advanced LED display system design and Christie’s quality, service and support, Christie Entero HB offers high brightness, 24/7 performance and reliability, all with an overall low cost of ownership and operation.
Control – The Entero HB series is the first and only LED control room display to offer wireless control through Wi-Fi capability – make adjustments, control the wall or perform diagnostic monitoring through an iPad® or other similar wireless device. It’s that simple.
Flexibility – The Christie Entero HB 70” SXGA+ video wall display cube, is part of a new expanded series of control room display cubes offering installation flexibility with options in resolution and display formats to meet specific room or space requirements.
Maintenance – Designed for zero maintenance, the Christie Entero HB series is solid state, has no consumables and no scheduled maintenance for at least 5 years.
The Christie Entero HB offers unparalleled 24/7 performance and years of worry-free operation. Plus, with simple, intuitive hardware installation, minimal set-up time and effort and modular design for fast and easy servicing if required, the new Christie Entero™ HB control room display cubes exceeds your expectations.
Features
- Up to 451 cd/m2 – high brightness mode / Up to 361 cd/m2 – normal mode
- 70” diagonal, SXGA+ (1400 x 1050) resolution
- high performance – high brightness, wide color gamut, superb contrast, excellent brightness and white level uniformity
- Wi-Fi enabled – wireless video wall control through iPad or similar wireless device
- Christie ArraySync™ third-generation automatic LED video wall color and brightness management
- 24/7 reliability – based on latest DLP® technology
- zero maintenance design – no consumables, no maintenance for at least 5 years
- low cost of ownership/operation
- shallow 31.8" depth requires minimal space allocation for 70” displays
- industry standard 4:3 aspect ratio
- only 1mm nominal space between screens
- geometric precision for seamless imaging across multiple displays
- reduced disruption because there are no consumable components to replace
- very wide color gamut for superior color reproduction
- ultra high contrast, view-ability and display performance
- designed for long-term use and performance – no need to replace in a few years
- >80,000 hours rated LED life (eco mode)
- modular design for minimal downtime if a repair is required
- dust free sealed optics
- permanently sealed liquid cooling system (no pumps or hazardous liquids)
Specifications
Product make-up
- Cube and Screen*: CF70-3601
- Projection engine: RPMWU-LED02
Imaging technology
- Imaging
- - Superior 0.95" 1-chip DLP®, Darkchip
- - Texas Instruments
- Native resolution: SXGA+ (1400 x 1050) | 4:3 aspect ratio
- Illumination: LED (Red, Green, Blue) | OSRAM | Redundant LED Architecture
Cross prism screen
- Optical: Fresnel/cross prism
- DNP
Screen gap (image to image)**
- 0.2-1.7mm
- Adjustable
- 1.7mm nominal recommended for front access @ 25°C
View-ability
- 180° Horizontal
- 120° Vertical
- +/- 35° Horizontal ½ gain
- +/- 27° Vertical ½ gain
System brightness
- Up to 451 cd/m2 in high brightness mode
- Up to 361 cd/m2 in normal mode
- Up to 304 cd/m2 in eco mode
